Inkmachines nr. 55 - Circlip pliers - 1pcs

Ink Machines

Product code: 375620

147,00 Lei

Fast delivery

Delivery 24-48h

14-day returnsWarrantyDelivery 24-48h

💵 Cash on delivery🔒 Secure order

Specifications

Brand: Ink Machines
Packaging: 1 pc
Material: Metal
Quantity: 1 pc
Compatibility: Dragonfly, Stingray
Usage: Assembly, disassembly
Motor type: Manual

Useful guides:Piese de schimb Ink Machines — Dragonfly, Stingray, Scorpion, Cobra: ghid InkMachines — mașini suedeze și piese de schimb (Dragonfly, Scorpion, Stingray, Cobra)Întreținerea mașinii de tatuat: piesele de schimb esențiale

Guide & full description

Complete guide: Inkmachines nr. 55 - Circlip pliers - 1pcs

This is an original Ink Machines service tool—a specialized plier for circlips (elastic retaining rings), i.e., the metal rings that secure rotating components axially inside a rotary tattoo machine. It is intended for artists and technicians who maintain their own Ink Machines: with it, you can safely install and remove circlips when changing cams, replacing bearings, or performing a full mechanism service. It is not a tool for working on skin, but a machine maintenance tool.

How to use

First, adjust the plier opening: the tips must open enough to release the circlip, but not excessively—if you stretch the ring too far, it loses elasticity and becomes unusable.
Identify the type of circlip you are working with: internal (sits in a housing and expands) or external (clips onto a shaft and compresses). The maneuver differs depending on the type.
Carefully insert the two precision tips into the manipulation holes of the circlip until they are firmly seated.
Squeeze the handles in a controlled manner to compress (external circlip) or expand (internal circlip) the ring just enough to clear the groove or pin.
Maintain steady, even pressure—do not release the pliers abruptly, otherwise the ring may fly off uncontrollably.
Guide the circlip into or out of its groove using small, controlled movements without forcing.
When installing, visually and, if possible, tactilely check that the ring is fully seated in the groove all around its circumference. A partially seated circlip may pop off during operation.
Wear safety glasses throughout the operation—circlips store elastic energy and can spring out unexpectedly.

Tips from us

First adjust the plier stroke on an old or test circlip to avoid overstretching the good ring.
Work on a clean, well-lit surface and ideally over a tray or towel—circlips are small and easy to lose if they spring away.
Never improvise with regular pliers, wrenches, or screwdrivers: you risk deforming the ring, scratching the machined surfaces of the machine, or injuring yourself.
Clean and degrease the mechanism components before reassembly so the circlip seats properly in the groove.
Keep the pliers clean and dry, and occasionally put a drop of fine lubricant at the pivot joint to maintain precision over time.

Warning: Circlips store energy and can fly off like a projectile if mishandled—always wear safety glasses. Adjust the plier opening so that you do not stretch the ring beyond its limit, otherwise it loses its retention force and must be replaced. Do not use improvised tools for circlips: the risk of ring deformation, damage to the machine's surfaces, and injury is high. Being a service tool, it does not come into contact with the client's skin; keeping it clean is part of machine maintenance, not sterilization of working instruments.

Frequently asked questions

What exactly is this plier used for on an Ink Machines machine?▾

It is designed for mounting and dismounting elastic circlips (retaining rings) in Ink Machines rotary machines. Circlips are metal rings that axially secure rotating components such as cams and bearings. Without a specialized plier, these rings cannot be safely handled because they store elastic energy and can spring uncontrollably if you use improvised tools.

Can I use a generic circlip plier instead of this one?▾

It is not recommended. The circlips in these machines are very small and require thin, precision tips that fit exactly into the ring's holes. Generic circlip pliers may have tips that are too thick, too long, or at the wrong angle, and combination pliers or screwdrivers are completely unsuitable. The correct tool protects an expensive machine from damage.

Which machines is it compatible with?▾

According to the description, the part is intended for service operations on Ink Machines Dragonfly and Stingray rotary machines. At tatuat.ro, it is also categorized under parts for Scorpion. If you have a different machine or model, check the product sheet or ask us before ordering to confirm compatibility.

When will I need to use the plier?▾

Most commonly when changing cams, which are fixed to the shaft with a circlip that must be removed and reinstalled. Also when replacing bearings, during a full rotary mechanism service (cleaning, lubrication, diagnostics), or whenever you need to access a part obstructed by a circlip.

Is the plier included with the purchase of the machine?▾

It depends on the model and configuration—some Ink Machines machines come with a basic accessory set that may include such a plier. Part number 55 is sold separately on tatuat.ro precisely for situations where you need it as a replacement or if it was not included in your machine's package.

How do I maintain the plier so it lasts?▾

Wipe it clean after use and keep it clean and dry, away from moisture, to prevent rust on the tips. Occasionally put a drop of fine lubricant at the joint so the pivot mechanism remains smooth and precise. Periodically check that the precision tips are not bent or chipped—they determine secure circlip grip.

Product description

Inkmachines nr. 55 - Circlip pliers Hint! Make sure to adjust the Circlip pliers gap so that it does not over stretch the Circlip or the Circlip will become useless. It should open just enougt so that the Circlip clears the pin. The InkMachines Circlip Pliers (part no. 55) are original circlip (snap ring) pliers designed for service and maintenance operations on InkMachines Dragonfly and Stingray rotary machines. This precision instrument is specifically designed for installing and removing circlips (retaining rings) that secure critical components of the rotary mechanism — cams, bearings, and other rotating parts — on shafts and in housings of the machine. Circlips are fastening elements that compress or expand to fit into circular grooves, locking parts in axial position without requiring screws or other threaded fasteners. Handling them without specialized pliers is extremely difficult and risky — attempting installation with generic pliers or screwdrivers can cause permanent circlip deformation (losing retention force), scratching of machined surfaces, or even launching the circlip as a projectile due to stored elastic tension. The InkMachines circlip pliers are calibrated for the specific dimensions of circlips in Dragonfly and Stingray machines, with thin precision tips that insert exactly into the circlip holes and a pivot mechanism providing the control needed for controlled compression or expansion. This instrument is essential for: changing cams (which requires removing the retention circlip), replacing bearings, and complete rotary mechanism service. Investing in original InkMachines circlip pliers represents critical insurance for your tattoo machine's integrity. A quality set of pliers prevents damage to circlips and machined machine surfaces, avoiding significantly higher repair costs from components damaged through inadequate handling. The precision tips of the original pliers are specifically calibrated for the circlip dimensions in InkMachines machines, ensuring secure grip and total control during installation and removal operations. Frequently Asked Questions
